Voltage Divider Calculator : A voltage divider circuit is a very common circuit that takes Vin voltage and converts (Vout) it less or equal to Vin by using one or a pair of resistors. The formula for calculating the output voltage is based on Ohms Law and is shown below.
The two resistors voltage divider is one of the most common and useful circuits used by engineers.
Enter any three known values and press \”Calculate\” to solve for the other. From dropdown select what value want to know in Result.
Voltage Divider Calculator
V
Where
Vin = the source voltage, measured in volts (V)
R1 = is the resistance of the 1st resistor, measured in Ohms (Ω).
R2 = is the resistance of the 2nd resistor, measured in Ohms (Ω).
Vout = is the Output Voltage. This is the converted voltage.
R1 = is the resistance of the 1st resistor, measured in Ohms (Ω).
R2 = is the resistance of the 2nd resistor, measured in Ohms (Ω).
Vout = is the Output Voltage. This is the converted voltage.
Multi-Stage Voltage Divider
V
